- Size: 3*0.85*1.5
- Place of Origin: China
- Brand Name: BETE
- Model Number: HXB3.0
- Weight: 2000.000 kg
PRODUCT INTRODUCTION
Brand New No.1 Foldable 3T Mini Crawler Crane in China with Overseas Training Service from Bete Factory
Quick Detail:
Lifting capacity: 3 tons
Gradeability: 30°
Boom length: 8.2m
Wireless remote control
Tip-over warning device
Slewing angle: 360° continuous
Maximum lifting height: 9.5m
Description:
HXB3.0 foldable 3Tx1.3m crane walks on a hydraulic crawler with hydraulic winching, stretching, up & down and slewing systems.
The equipment adopts some advanced design method and idea like solidworks 3D, ANSYS Element analysis of limit and computerization of total machine.
Therefore, it has many advantages such as better flexibility, convenient operation, compact structure, stable performance, reliable use and convenient maintenance.
Applications:
The HXB3.0 crane is widely applied to lifting especially in some narrow space where heavy-duty crane cannot get in.
Don't know how to use the crane? Doesn't matter at all.
We have overseas crane training service for you at your office.
After theoretical and practical training, you will know how to use the cranes.
Technical data
Model | HXB3.0 | |
Crane capacity | 3.0t×1.3m | |
Maximum working radius | 7.7m | |
Maximum lifting height | 9.5m | |
Winch | Hook up speed | 2.8m/min(4 times) |
Diameter and length of wire rope | Ø8mm×50m | |
Telescopic | Boom form | 4 (4 Automatic) |
Boom length | 8.2 m | |
Derrick | Derricking angle | 0-75° |
Slewing | Slewing angle | 360-degree continuous |
Outrigger | Form of outrigger | First phase--automatic Second phase--manual |
Maximum extend range | 5.3m | |
Traction system | Travel | Hydraulic |
Travel speed | 0-3.0km/h | |
Track | Synthetic rubber | |
Gradeability | 30° | |
Track ground pressure | 50kpa | |
Engine and machine parameters
Engine | Model | HONDA GX390 |
Displacement | 389.2ml | |
Outputpower | 13HP(9.6KW) | |
Starting method | Electric and Recoil Start | |
Fule/Fule tank capacity | Automotive gasoline/6L | |
Hydraulic(crane) | Tank capacity | 38L |
L×W×H | 3.0m×0.8m×1.5m | |
Total weight | 2,000kg | |
